TELEVAC CC-10 - 2.2 Rear panel; 2.3 Sensor

CC-10
INSTRUMENT MANUAL
Phone:(215) 947-2500 fax:(215) 947-7464 e-mail:sales@televac.com web site:www.televac.com
CC-10 MANUAL REV D
Page 6 of 40
Y
TELEVA
2.2 Rea r p a n e l
2.3 Se nso r
1. Sensor access
screws screws
1. Anti rotation slot
2. Anode pin
3. Crystal sensor pins
4. Ground pins
1
1
4
2
3
