TELEVAC CC-10 - S (Status) Command

CC-10
INSTRUMENT MANUAL
Phone:(215) 947-2500 fax:(215) 947-7464 e-mail:sales@televac.com web site:www.televac.com
CC-10 MANUAL REV D
Page 29 of 40
Y
TELEVA
1. host to gauge
1 2 3 4 5
< STX>
Address
(HEX)
S
mode
< CR>
2. gauge to host
1 2 3 4 5 6 7 8
< STX>
Address
(HEX)
S
response data
< CR>
3. Command & response
command
mode
Explanation
Response
data
Explanation
1
Read pressure data
ppse
pp: mantissa
s : sign (0” -“ , 1= ” + ” )
e : exponent
2
Read error status
0001
Measure
0002
Error (ErrO, AdEr, CALE, EE
Error)
5
Read SP1, SP2, SP3 HV
Status
ABCD
A : SP1 Status
0 = OFF, 1 = ON
B : SP2 status
0 = OFF, 1 = ON
C : SP3 Status
0 = OFF, 1 = ON
D : HV Status
0 = OFF, 1 = ON
6
Read mode status
0000
Measure mode
0001
Program mode(parameter set
mode)
7
Read error code
ABCD
A : Erro
0 = normal, 1 = Erro
B : AdEr
0 = normal, 1 = AdEr
C : CALE
0 = normal, 1 = CALE
D : EE Erro
0 = normal, 1 = EE Erro
8
Read unit model
D010
CC-10
9
Read software version
Vxxx
X : integer
S (status) command
