2.0 U s e r C on t r o l s
2.1 F r on t p a n e l
1. Pressure indicator
2. Set point status indicator
3. High Voltage status indicator
4. Function key
5. Up key
6. Shift key
7. Enter key
8. I/O connector
2
5
4
1
7
8
3
6
