7 Network
7.1 Mobile
7.1.1 General
7.1.1.1 Mobile configuration
Here you can configure mobile settings which are used when connecting to your local 3G/LTE network.
PPP mode uses dialling number to establish data connection.
NDIS mode (default) does not use dialling and PPP protocol to
establish data connection it is usually faster than PPP mode.
NAT / Passthrough / Use
bridge
NAT mode enables network address translation on router. Bridge
mode bridges LTE data connection with LAN. In this mode the router
does not have internet connection as ISP provides IP directly to end
device (PC, tablet or smart phone).Using Bridge mode will disable
most of the router capabilities and you can access your router's
settings only by using static IP address on your end device.
Passthrough mode is similar with bridge mode except that in
passthrough mode router does have internet connection.
Access Point Name (APN) is a configurable network identifier used
by a mobile device when connecting to a GSM carrier.
“1234” or any number
that falls between 0000
and 9999
A personal identification number is a secret numeric password
shared between a user and a system that can be used to
authenticate the user to the system.
Dialling number is used to establish a mobile PPP (Point-to-Point-
Protocol) connection.
Authentication method, which your carrier uses to authenticate new
connections. (This selection is unavailable on the alternate model)
Your username that you would use to connect to your carriers
network. This field becomes available when you select an
authentication method (i.e. authentication method is not “none”).
These fields are always enabled on the alternate model.
Your password that you would use to connect to your carriers
network. This field becomes available when you select an
authentication method (i.e. authentication method is not “none”).
These fields are always enabled on the alternate model.
