Teo IP Phone 4101 Installation Instructions
Page 18 13-280135 Rev. K
I
I
n
n
i
i
t
t
i
i
a
a
l
l
i
i
z
z
a
a
t
t
i
i
o
o
n
n
w
w
i
i
t
t
h
h
o
o
u
u
t
t
D
D
H
H
C
C
P
P
S
S
e
e
r
r
v
v
e
e
r
r
The DHCP (Dynamic Host Configuration Protocol) server automatically assigns the
telephone address, server addresses, and subnet mask. If DHCP is not available, or is not
provisioned with all of these parameters, they must be entered manually.
The following display will be shown while the phone attempts to connect to a DHCP server.
• If no DHCP server is available, select DISABLE (press the
ENTER key) to use static
addressing.
• Press the Right Arrow key repeatedly to move to the end of the line, and then press
the Left Arrow repeatedly to remove the displayed IP address.
• Enter the phone’s IP address with the dial pad; use the
*
key to enter a ".". Press the
ENTER key when finished.
• Enter the required subnet mask and gateway IP address when prompted; press the
ENTER key after each entry.
Next, the phone will prompt for an update server protocol and IP address.
• Select a protocol with the Up Arrow or Down Arrow key, and then press the
ENTER
key. Enter the update server IP address when prompted. Press the
ENTER key when
finished. If no update server is available, select NONE.
The phone then will prompt for the Line ID, authentication ID, and SIP password as shown
on the previous page.
U
U
s
s
i
i
n
n
g
g
L
L
o
o
c
c
a
a
l
l
I
I
n
n
s
s
p
p
e
e
c
c
t
t
t
t
o
o
V
V
e
e
r
r
i
i
f
f
y
y
K
K
e
e
y
y
s
s
Local Inspect (page 48) allows you to identify the line appearance or feature assignment of
each configured key, directory number bearer capabilities, and the feature indicator
assignment for the Message Waiting Indicator.
UPDATE>PROTOCOL
TEO
PHONE IP ADDR=
_
PHONE IP ADDR=
000.000.000.000
CHECKING DHCP
DISABLE?
