Terex MAC 25 - Page 66

LMI DUTY
310
MAC-25 BUTT LUG - 10 DEG. ART. MAC-25 BUTT LUG - 40 DEG. ART.
STANDARD 1500 KG COUNTERWEIGHT (PLMXF2009)
+ EXTRA 2160 KG COUNTERWEIGHT (PLMXF2019-) ON REAR OF CRANE - SPRING LOCKOUTS ENGAGED
RC IN KILOGRAMS FOR SLEW ANGLES OF 10 DEGREES OR LESS EITHER RC IN KILOGRAMS FOR SLEW ANGLES OF GREATER THAN 10 DEGREES UP TO 40
SIDE OF STRAIGHT AHEAD (INDICATED BY GREEN LED ON DASH). DEGREES EITHER SIDE OF STRAIGHT AHEAD (INDICATED BY RED LED ON DASH).
BOOM ANGLE - UNDEFLECTED (REF.) BOOM ANGLE - UNDEFLECTED (REF.)
NOTE :
VALUES IN BRACKETS ( ) ARE ACTUAL RADIUS AT ZERO DEG. BOOM ANGLE.
NOTE :
VALUES IN BRACKETS ( ) ARE ACTUAL RADIUS AT ZERO DEG. BOOM ANGLE.
RC IS AT THIS RADIUS RC IS AT THIS RADIUS
RC ARE BASED ON 66.6% STABILITY & STRENGTH - RC ABOVE BOLD RED LINE ARE STRUCTURAL
RC ARE BASED ON FIRM, LEVEL GROUND (1% SLOPE (0.6 DEG) AS PER AS1418.5) WITH TYRES INFLATED AS PER NOTES
LIFT & CARRY - THE RC SHALL BE CARRIED WITH THE MINIMUM BOOM LENGTH & AS CLOSE TO THE GROUND AS POSSIBLE AT SPEEDS NOT IN EXCESS OF 0.4 m/s (1.44 km/h)
NOTE : WEIGHT OF HOOKS, BLOCKS & OTHER LOAD HANDLING DEVICES SHALL BE ADDED TO THE WEIGHT OF THE LOAD
Boom Boom
Radius
Length
Radius
Length
in
(metres)
in
(metres)
Metres
4.81
Metres
4.81
1.4 25000 1.4 25000
32 32
1.5 25000 1.5 25000
30
NOTE : WEIGHT OF HOOKS, BLOCKS & OTHER
30
1.6 24650
LOAD HANDLING DEVICES SHALL BE ADDED
1.6 24650
27
TO THE WEIGHT OF THE LOAD
27
1.7 24200 1.7 24200
24 24
1.8 23800 1.8 23800
21 21
1.9 23400 1.9 23400
18 18
2.1 22600 2.1 22050
0 0
63/66 MXC1347B 16.6t RAW COUNTERWEIGHT - REAR MAC 25 BUTT LUG 10 / 40 DEG
