Terex MAC 25 - Page 67

LMI DUTY
311
MAC25 LUG 1 LOAD CHART - 10 DEG. ART. MAC25 LUG 1 LOAD CHART - 40 DEG. ART.
STANDARD 1500 KG COUNTERWEIGHT (PLMXF2009)
+ EXTRA 2160 KG COUNTERWEIGHT (PLMXF2019-) ON REAR OF CRANE - SPRING LOCKOUTS ENGAGED
RC IN KILOGRAMS FOR SLEW ANGLES OF 10 DEGREES OR LESS EITHER RC IN KILOGRAMS FOR SLEW ANGLES OF GREATER THAN 10 DEGREES UP TO 40
SIDE OF STRAIGHT AHEAD (INDICATED BY GREEN LED ON DASH). DEGREES EITHER SIDE OF STRAIGHT AHEAD (INDICATED BY RED LED ON DASH).
BOOM ANGLE - UNDEFLECTED (REF.) BOOM ANGLE - UNDEFLECTED (REF.)
NOTE : VALUES IN BRACKETS ( ) ARE ACTUAL RADIUS AT ZERO DEG. BOOM ANGLE NOTE : VALUES IN BRACKETS ( ) ARE ACTUAL RADIUS AT ZERO DEG. BOOM ANGLE
RC IS AT THIS RADIUS RC IS AT THIS RADIUS
RC ARE BASED ON 66.6% STABILITY & STRENGTH - RC ABOVE BOLD RED LINE ARE STRUCTURAL
RC ARE BASED ON FIRM, LEVEL GROUND (1% SLOPE (0.6 DEG) AS PER AS1418.5) WITH TYRES INFLATED AS PER NOTES
LIFT & CARRY - THE RC SHALL BE CARRIED WITH THE MINIMUM BOOM LENGTH & AS CLOSE TO THE GROUND AS POSSIBLE AT SPEEDS NOT IN EXCESS OF 0.4 m/s (1.44 km/h)
NOTE : WEIGHT OF HOOKS, BLOCKS & OTHER LOAD HANDLING DEVICES SHALL BE ADDED TO THE WEIGHT OF THE LOAD
RADIUS
BOOM PIVOT TO LUG 1, 1st EXTENSION, THIRD EXTENSION RETRACTED
RADIUS
BOOM PIVOT TO LUG 1, 1st EXTENSION, THIRD EXTENSION RETRACTED
IN
(metres)
IN
(metres)
METRES
5.36 5.50 6.00 6.50 7.00 7.50 8.00 8.50 9.00 9.46
METRES
5.36 5.50 6.00 6.50 7.00 7.50 8.00 8.50 9.00 9.46
1.4
25000 25000 25000 25000 25000 25000 25000 25000 25000 24000
1.4
22600 21750 19350 17600 16150 15000 14000 13200 12450 11800
40 42 47 51 54 57 59 61 63 64 40 42 47 51 54 57 59 61 63 64
2
23900 23850 23650 23500 23300 23150 22950 22750 22600 21350
2
23800 22900 18750 16600 15050 13850 12850 12000 11300 10700
29 31 38 44 48 51 54 56 59 60 29 31 38 44 48 51 54 56 59 60
2.5
21000 20950 20700 20450 20250 20050 19900 19750 19600 19500
2.5
18700 18650 18400 16800 14250 13000 11950 11150 10450 9900
14 19 30 37 42 46 49 52 55 57 14 19 30 37 42 46 49 52 55 57
3
18600 18000 16900 16700 16550 16400 16250 16100 16000 15900
3
17500 16450 15000 14800 13950 12950 11200 10350 9650 9150
(2.7) (2.8) 18 29 35 41 45 48 51 53 (2.7) (2.8) 18 29 35 41 45 48 51 53
3.5
15200 14050 13900 13750 13600 13500 13400 13300
3.5
13450 12400 12250 11750 10950 9650 8950 8450
(3.3) 17 28 34 39 43 46 49 (3.3) 17 28 34 39 43 46 49
4
12750 11900 11750 11650 11550 11450 11350
4
11200 10450 10350 10000 9350 8800 7850
(3.8) 17 27 33 38 42 45 (3.8) 17 27 33 38 42 45
5
10850 9350 8850 8800 8700 8650
5
9500 8150 7700 7650 7400 7000
(4.3) (4.8) 16 25 31 36 (4.3) (4.8) 16 25 31 36
6
8150 7150 6850 6800
6
7050 6150 5900 5850
(5.3) (5.8) 15 23 (5.3) (5.8) 15 23
6.8
6300 5650
6.8
5400 4800
(6.3) (6.8) (6.3) (6.8)
64/66 MXC1347B 16.6t RAW COUNTERWEIGHT - REAR MAC 25 LUG 1 - 10 / 40 DEG
