Lubrication and Servicing
8-10
* - Capacities given are approximate, work to dipstick, sight gauges or level plugs.
Note 1 - The use of low viscosity oils, such as 10W-30 or 5W-30, can be used to aid in starting the engine and
providing sufficient oil flow at low ambient temperatures. Continuous use of low viscosity oils can decrease
engine life due to adverse wear.
Note 2 - Operation below the minimum temperatures listed for the oil used without proper preheat or warm-up
results in greatly reduced transmission life. Proper warm-up requires 20 minutes minimum operation in neutral
(with engine at part throttle) before operating the transmission in gear.
Note 3 - Hydraulic Transmission Oil meeting Specification EMS19058 is suitable for use in the hydraulic sys-
tem.
Note 4 - Automatic Transmission Fluids (ATF) may only be used when the ambient temperature is less than -
10° C (14° F). Should the temperature increase, it is necessary to switch to engine oil.
Note 5 - Maximum 1.5% of Lubrizol (TEREX Part No. 15250489), may be added to planetary capacity to pre-
vent brake squeal.
Any increase in the stated volume of Lubrizol will result in a decrease in brake performance.
Note 6 - Volume of Lubrizol to each planetary is as follows:
Front: Maximum 1.5% = 165 ml (5.57 oz)
Centre and Rear: Maximum 1.5% = 110 ml (3.71 oz)
RECOMMENDED LUBRICANTS
COMPONENT LUBRICANT *CAPACITY SPECIFICA-
TIONS
API
CODE
SAE GRADE
Engine Crankcase
(Including Filters)
Engine Oil with 1.00% sulphated ash limit is rec-
ommended. Sulphated ash must not exceed
1.85% limit
45 Litres(11.8 US gal) CH-4 15W-40 (See
Note1)
Transmission (Including
cooler)
Engine Oil with 1.85% max. sulphated ash limit
55 Litres (14.5 US gal)
(See Note 2) CH-4 15W-40 See
Trans. Oil
Ta bl e.
Transmission Cooler
Engine Oil with 1.85% max. sulphated ash limit
8.25 Litres (2.18 US gal)
(See Note 2) CH-4 15W-40 See
Trans. Oil
Ta bl e.
Hydraulic System
(Including Lines)
Hydraulic Transmission Oil
256 Litres (67.2 US gal)
See Hydraulic Oil Table
(See Note 3)
Cooling System Anti-freeze, Ethylene Glycol
48.8 Litres (12.8 US gal)
Differential (Front and
Rear)
Extreme Pressure Gear Lubricant
21 Litres each (5.5 US
gal)
MIL-L-2105 GL-5 80W-90 H
Differential (Centre)
Extreme Pressure Gear Lubricant
23.0 Litres (6.0 US gal)
MIL-L-2105 GL-5 80W-90 H
Planetaries (Front) Extreme Pressure Gear Lubricant
11.75 Litres each (3.1 US
gal)
MIL-L-2105
See Notes 5
and 6)
GL-5 80W-90 H
Planetaries (Centre &
Rear) each
Extreme Pressure Gear Lubricant
7.5 Litres each (2.0 US
gal)
MIL-L-2105
(See Notes 5
and 6)
GL-5 80W-90 H
Fuel Tank Diesel Fuel Oil with max. sulphur 0.5%
370 Litres (98 US gal)
DIN EN590
Grease Nipples Extreme Pressure Lithium Grease No.2 Consis-
tency
Drive shaft through
Bearings
Extreme Pressure Gear Lubricant 0.125 Litres (0.033 US gal) MIL-L-2105 GL-5 80W-90
Articulation Bearings Extreme Pressure Lithium Complex EMS 19057
Hand Pump Tank Hydraulic Transmission Oil
1 Litre (0.26 US gal)
See Hydraulic Oil Table
(See Note 3)
Def Tank Capacity Urea
52 Litres
WARNING
