Controls and Operating
3-27
Seat Belt
Retractable seat belts (1) are installed on both the operator’s seat and the
jump seat. The seat belts require no external adjustment and allow free-
dom of movement for proper manipulation of all controls.
NOTICE: To extract the jump seat belt, the button on the housing must be
pressed.
Always wear seat belt when operating the machine.
Always check condition of seat belts and mounting hardware
before operating the machine.
Any signs of looseness or wear should be reported to your Ser-
vice Department or Dealer for repair or replacement immedi-
ately.
Replace the seat belt at least once every three years, regardless of
appearance.
Stop the machine; apply park brakes; then carry out adjustments.
Trainer / Instructor Seat
The trainer/instructor seat has only to be used when operator training
or instruction is being performed, or for service personnel performing
service diagnostics.
NOTICE: The Trainer/instructor seat is NOT for continuous passenger
use.
To access the compartment below the instructor seat, lift the seat (1)
and use the strap to hold the seat in position (2). The seat backrest
can be folded down when not in use. Pull the seat release catch,
located on the side of the seat, to unlock the backrest (3). The back-
rest can now be folded down (4).
NOTICE
The backrest must be
unlocked using the release
catch before attempting to
fold it down. Failure to do
this will damage the seat
