Controls and Operating
3-35
Error Code Description of Error Check
27 MCU OUT_08 X1:2 SHORT E5_HighBeam_Left_ON
28 MCU OUT_08 X1:2 BREAK E5_HighBeam_Left_ON
29 MCU OUT_09 X1:3 SHORT P8_FlashingReverseLamp_ON
30 MCU OUT_09 X1:3 BREAK P8_FlashingReverseLamp_ON
31 MCU OUT_10 X1:4 SHORT E6_LowBeam_Right_ON
32 MCU OUT_10 X1:4 BREAK E6_LowBeam_Right_ON
33 MCU OUT_11 X1:5 SHORT E20_ReverseLamp_ON
34 MCU OUT_11 X1:5 BREAK E20_ReverseLamp_ON
35 MCU OUT_12 X1:6 SHORT K8_Horn_ON
36 MCU OUT_12 X1:6 BREAK K8_Horn_ON
37 MCU OUT_13 X1:7 SHORT E11_WorkLights_Front_ON
38 MCU OUT_13 X1:7 BREAK E11_WorkLights_Front_ON
39 MCU OUT_14 X1:8 SHORT Q7_TransFan_OFF
40 MCU OUT_14 X1:8 BREAK Q7_TransFan_OFF
41 MCU OUT_15 X1:9 SHORT Reserve
42 MCU OUT_15 X1:9 BREAK Reserve
43 MCU OUT_00E X2:18 SHORT M2_WashPump_Front_ON
44 MCU OUT_00E X2:18 BREAK M2_WashPump_Front_ON
45 MCU OUT_01E X2:17 SHORT Reserve
46 MCU OUT_01E X2:17 BREAK Reserve
47 MCU OUT_02E X2:16 SHORT E6_HighBeam_RIGHT_ON
48 MCU OUT_02E X2:16 BREAK E6_HighBeam_RIGHT_ON
49 MCU OUT_03E X2:15 SHORT K16_RearWiper_ON
50 MCU OUT_03E X2:15 BREAK K16_RearWiper_ON
51 MCU OUT_04E X2:14 SHORT Reserve_PWM
52 MCU OUT_04E X2:14 BREAK Reserve_PWM
53 MCU OUT_05E X2:13 SHORT Reserve
54 MCU OUT_05E X2:13 BREAK Reserve
