Safety
SAFETY DECAL SET ISO STANDARD
ROPS FOPS
SAE ISO SAE ISO lb MAX. kg MAX. TEREX No.
15335811
S/N
ROPS and FOPS, See handbook for procedure (1931)
30 1C 1 0.3 30 1L 10 5
25 1C 3 1 25 2 15 9
20 1L 5 3 20 3 22 14
15 1L 9 5 15 4 28 17
10 2 15 9 10 4 34 21
5 4 30 17 5 5 54 33
0 5 55 34 0 5 55
34
15335771
%
KPH MPH
%
KPH MPH
Gradeability Chart, TR35 (1910)
15335785
Hydraulic Oil Sight
Gauge (1906)
N
15335788
P
1. 2.
Warning park brake (1925)
15335864
Backalarm Warning, Operator
must make certain back alarm is
operating properly (1923)
15335820
P
30 30 1L 11 6
25 1C 5 3 25 1L 12 7
20 1C 6 3 20 2 16 9
15 1L 10 6 15 3 20 12
10 2 15 9 10 4 31 19
5 4 30 18 5 6 59 36
0 6 66 41 0 6 66
41
15335774
%
KPH MPH
%
KPH MPH
Gradeability chart TR45 (1912)
30 1C 2 1 30 2 12 7
25 1C 5 3 25 3 15 9
20 1L 8 5 20 3 18 11
15 1L 10 6 15 4 24 15
10 3 16 10 10 5 35 21
5 5 30 18 5 6 58 36
0 6 60 37 0 6 60
37
15335776
%
KPH MPH
%
KPH MPH
Gradeability chart, TR60 (1914)
15336277
N
2
PSI / BAR
0
Suspension Strut (2198)
