2-25
Safety
SAFETY DECAL SET ANSI STANDARD
Warning, Crush hazard (1909)
30 30 1L 10 6
25 1C 1 1 25 2 12 8
20 1C 5 3 20 3 16 10
15 1L 9 5 15 4 20 12
10 2 12 7 10 5 34 21
5 4 27 16 5 6 58 35
0 6 60 37 0 6 60
37
15335777
%
KPH MPH
%
KPH MPH
Gradeability chart, TR70 (1916)
Gradeability chart, TR100 (1918)
15335789
Caution Cab Foam, Do not weld or burn cab
structure unless foam is removed (1920)
15335792
Rim clamps, See handbook for procedure
(1928)
15335749
Crush Hazard, Install support
before servicing (1908)
15335744
Crush Hazard
Death or serious
injury may result.
Install support
before servicing.
WARNING
30 30 2 11 7
25 1C 5 3
1C 4 2
25 2 14 9
20 1L 8 4 20 3 16 10
15 1L 9 5 15 4 22 13
10 2 14 9 10 5 32 19
5 4 27 16 5 6 49 31
0 6 49 31 0 6 49
31
15335778
%
KPH MPH
%
KPH MPH
Hot Radiator Steam Warning (1823)
15335954
NOTICE
Welding truck can seriously
damage ECUs and
components.
Disconnect the following,
in order, before welding:
1. Turn off master switch.
2. Battery earth cable.
3. Battery supply cable.
4. Alternator earth cable.
5. Alternator supply cable.
6. Body control lever.
7. Engine ECM.
8. Transmission ECU.
9. Cab bulkhead connectors
Warning Alternator (2197)
15333278
Burn Hazard.
Hot fluid under
pressure can scald.
Allow to cool before
opening.
WARNING
