Working Under the Lift – ALWAYS FIT SAFETY SCOTCH
1.
RAISE LIFT TO ABOVE
THE RAM FIXING BOLT
HOLE IN THE LH GUIDE
3.
ROTATE SCOTCH
DOWNWARDS
4.
SECURED POSITION.
REMEMBER TO
REMOVE THE SCOTCH
BEFORE OPERATING
THE LIFT NORMALLY.
2.
HOOK THE SAFETY
SCOTCH INTO THE HOLE
Important:
Before any work is carried out underneath
the lift, the safety scotch must be fitted to
the LH guide as indicated below.
The safety scotch can be found within the
powerpack and after use must be put
back there, so it remains with the lift.
