Old Style Seat Design
With this design, the seat must be
fitted to the car side frames BEFORE
the inner side panels are fitted.
1. Fit bracket to car sides with two
M6 x 16 csk screws.
2. Fix seat to bracket using four M6 x 30 skt csk screws.
