STEP 1 - REMOVE THE PALLET
Caution: Leave the front cover of the box ON for structural stability while lifting.
Note: Two people are needed for this procedure.
1. Lay the box flat on the ground with the pallet side down.
2. Cut and remove the shipping straps around the box.
3. Use a T25 Torx to remove 2 screws from each of the 8 blocks on the box sides (shown in the
next image). Do not remove the screws near the corners of the box.
4. With the front cover still on, lift up the sides of the box and move it sideways until the top of
the box touches Powerwall inside. This leaves room for the bottom of the box to
flex without
damaging Powerwall's bottom cover.
5. Align the lower edge of the box between the upper and lower wood blocks on the sides of the
Powerwall.
6. Use a T25 Torx to securely attach the same 2 screws into each of the 4 upper blocks attached
to the sides of the Powerwall. Now the Powerwall is secured to the sides of the box with the
top blocks, and the bottom blocks remain with the pallet.
7. With one hand on the front cover and one hand under the pallet towards the top corner, both
installers carefully tilt the box up onto its bottom end so that the printed Powerwall image on
the package cover is standing right side up. Ensure the box is in a stable location, such as
against a wall, where it will not be bumped or tip over.
Step-by-Step Installation Instructions
10
