5 First steps
29
Options:
> Toggle between upper/lower case:
select Ι← ABC→&$/ →Ι: [▲], [▼] → [ABC→&$/].
> Position the cursor in the text:
select Ι← ABC→&$/ →Ι: [▲], [▼] → [Ι←] or [→Ι].
> Delete character before or after the cursor:
select ← next → [▲], [▼] → [←] or [→].
3. Repeat steps 1 and 2 as required.
4. Save the entry: Select ← next → [▲], [▼]
→ [Next].
5.2.6. Printing/saving data
Data is printed out via the key [ ]. Data is saved via the Options
menu. The Options menu is accessed via the left function key and
is available in many different menus.
To assign the right function key with the Save function or see
Assigning the right function key, page 34,
Only readings assigned a display field in the measurement view will
be saved / printed out.
The measurement data can be printed out parallel to the
saving process, while a measurement program is running.
To be able to transfer data to a record printer via infrared or
Bluetooth interface, the printer used must be enabled, see
Instrument diagnosis, page 33.
5.2.7. Saving data to the clipboard (temporary memory)
Using the clipboard, measurement results from various
measurement types can be combined to produce a common
record, which can then be printed out (see above). Data is saved to
the clipboard via the Options menu and the Clipboard command.
If there is data in the clipboard, the status bar shows the symbol .
If there is data in the clipboard and the Print command is triggered,
all data in the clipboard will be printed out.
5.2.8. Confirming an error message
If an error occurs, an error message is shown on the display.
> Confirming an error message: [OK].
Errors that have occurred but have not yet been rectified are
indicated by a warning symbol ( ) in the header.
Error messages that have not yet been cancelled can be displayed
in the Error diagnosis menu, <dg_ref_source_inline>.
