Installation
12
Installation
Risks resulting from incorrect installation!
Install Testomat
®
808 at a location where it is protected against
dripping or splash water, dust and aggressive substances – e.g. in
a control cabinet or on a suitable wall.
Information for trouble-free operation
Install Testomat
®
808 vertically and without mechanical stress.
Install Testomat
®
808 at a vibration-free site.
Installing Testomat
®
808
Select an installation site where the water inlet hose can be kept as
short as possible (max. 5 m).
Drill the mounting holes as shown in the drawing below.
Use three screws to attach the instrument at a suitable position on
the wall.
