Description of the relay outputs
25
Switch
position
Relay K2
(message poor analysis)
Relay K1
(external flush)
Comment
for relay K2
0
Normally open – closes in
case of 1 poor analysis,
remains closed until the next
good analysis
Normally open – closes after a
poor analysis for 1 minute
Continuous contact can be deleted
via key 4 (horn) or “Delete external-
ly”. Measures continue despite mes-
sage via the relay K3.
1
Normally open – closes in
case of 1 poor analysis,
remains closed until the next
good analysis
Normally open – closes after a
poor analysis for 3 minutes
Continuous contact can be deleted
via key 4 (horn) or “Delete external-
ly”. Measures continue despite mes-
sage via the relay K3.
2
Normally open – closes after
2 poor analyses, remains
closed until the next good
analysis
Normally open – closes after
the first poor analysis for 1
minute and after the second
poor analysis for 2 minutes
Continuous contact can be deleted
via key 4 (horn) or “Delete external-
ly”. The instrument skips the interval
pause after the first poor analysis.
Measures continue despite mes-sage
via the relay K3.
3*
Normally open – closes after
3 poor analyses, remains
closed until the next good
analysis
Normally open – closes after
the first poor analysis for 1
minute, after the second poor
analysis for 2 minutes and
after the third poor analysis for
3 minutes
Continuous contact can be deleted
via key 4 (horn) or “Delete external-
ly”. The instrument skips the interval
pause after the first and second poor
analysis. Measures continue despite
mes-sage via the relay K3.
4
Normally open – closes in
case of 1 poor analysis and
remains closed.
Opens again once the alarm
has been deleted
Instrument goes into standby. Con-
tinuous contact can be deleted via
key 4 (horn) or “Delete externally”.
5
Normally open – closes after
2 poor analyses and re-
mains closed.
Opens again once the alarm
has been deleted
Normally open – closes after
the first poor analysis for 1
minute
Instrument goes into standby. Con-
tinuous contact can be deleted via
key 4 (horn) or “Delete externally”.
The instrument skips the interval
pause after the first poor analysis.
6
Normally open – closes after
3 poor analyses and re-
mains closed.
Opens again once the alarm
has been deleted
Normally open – closes after
the first poor analysis for 1
minute and after the second
poor analysis for 2 minutes
Instrument goes into standby. Con-
tinuous contact can be deleted via
key 4 (horn) or “Delete externally”.
The instrument skips the interval
pause after the first and second poor
analysis.
7
Normally open – closes in
case of 1 poor analysis,
remains closed until the next
good analysis
Normally open – closes for
90 s before the analysis
Continuous contact can be deleted
via key 4 (horn) or “Delete externally”
Measures continue despite mes-sage
via the relay K3.
8
Normally open – closes after
the 2 poor analyses for 1
minute
Normally open – closes after
the first poor analysis for 1
minute and after the second
poor analysis for 2 minutes
The instrument skips the interval
pause after the first poor analysis.
Measures continue despite mes-sage
via the relay K3.
9
Normally open – closes after
the 3 poor analyses for 1
minute
Normally open – closes after
the first poor analysis for 1
minute, after the second poor
analysis for 2 minutes and
after the third poor analysis for
3 minutes
The instrument skips the interval
pause after the first and second poor
analysis. Measures continue despite
mes-sage via the relay K3.
* Delivery status
