EVM Bill of Materials www.ti.com
72
SLOU489–August 2017
Submit Documentation Feedback
Copyright © 2017, Texas Instruments Incorporated
Hardware Reference
Table 3. AFE5832 EVM Bill of Materials
(1)
(continued)
Designator Quantity Value Description
Package
Reference
PartNumber Manufacturer
Alternate
Part Number
Alternate
Manufacturer
C65, C66, C67,
C68, C69, C70,
C71, C72, C73,
C74, C76, C77,
C78, C79, C80,
C81, C82, C83,
C84, C85, C86,
C87, C88, C90,
C91, C92, C93,
C94, C95, C96,
C99, C100, C101,
C102, C103, C104,
C105, C106, C107,
C108, C109, C110,
C111, C112, C113,
C114, C115, C116,
C117, C118, C119,
C120, C121, C122,
C123, C124, C125,
C126, C132, C136,
C139, C141, C142,
C143, C144, C146,
C147, C148, C149,
C150, C151, C155,
C157, C162, C167,
C168, C169, C170,
C171, C172, C210,
C211, C212, C213,
C214, C217, C218,
C219, C220, C230,
C233, C235, C237,
C239, C249, C252,
C253, C256, C257,
C258, C259, C261,
C262, C263, C264,
C265, C266
107 0.1µF
CAP, CERM, 0.1
µF, 16 V, +/- 10%,
X7R, 0402
0402
GRM155R71C104
KA88D
MuRata
C75 1 10µF
CAP, CERM, 10
µF, 6.3 V, +80/-
20%, Y5V,
0805_140
0805_140
GRM21BF50J106Z
E01L
MuRata
C97 1 10µF
CAP, CERM, 10
µF, 6.3 V, +/- 20%,
X5R, 0603
0603
C0603C106M9PA
CTU
Kemet
C98, C231, C232 3 1000pF
CAP, CERM, 1000
pF, 6.3 V,+/- 10%,
X5R, 0402
0402
GRM155R60J102K
A01D
MuRata
