Table 3. AFE5832 EVM Bill of Materials
(1)
(continued)
Designator Quantity Value Description
Package
Reference
PartNumber Manufacturer
Alternate
Part Number
Alternate
Manufacturer
H1, H5, H8, H13,
H16
5
HEX STANDOFF
4-40 ALUMINUM
1/2"
HEX STANDOFF
4-40 ALUMINUM
1/2"
2203 Keystone
H2, H6, H9, H12,
H15
5
HEX, M-F
STANDOFF 4-40
ALUMINUM 5/8"
HEX, M-F
STANDOFF 4-40
ALUMINUM 5/8"
8402 Keystone
H3, H7, H10, H11,
H14
5
MACHINE SCREW
PAN PHILLIPS 4-
40
Machine Screw, 4-
40, 1/4"
PMSSS 440 0025
PH
B&F Fastener
Supply
H4 1
CABLE ASSY STR
2.1MM 6' 24 AWG
CA-2185 Tensility
J1, J4, J8, J11,
J14, J17, J21, J24,
J27, J30
10
Connector, End
launch SMA, 50 Ω,
SMT
End Launch SMA 142-0701-801 Johnson
J2, J3, J5, J6, J9,
J10, J12, J13, J15,
J16, J19, J20, J22,
J23, J25, J26, J28,
J29, J31, J32, J33,
J34, J37, J39, J43,
J46, J51, J52, J56,
J59, J66, J68
32
SMA Straight PCB
Socket Die Cast,
50 Ω, TH
SMA Straight PCB
Socket Die Cast,
TH
5-1814832-1 TE Connectivity
J7, J18, J48 3
Socket, 0.5MM,
60x2, Gold, SMT
Socket, Female,
0.5MM, 60x2, SMT
QTH-060-01-L-D-A Samtec
J35, J36, J41, J53,
J57
5
Header, 100mil,
2x1, Gold, TH
2x1 Header TSW-102-07-G-S Samtec
J38, J60 2
Header, 100mil,
4x2, Gold, TH
4x2 Header TSW-104-07-G-D Samtec
J40, J42, J44, J45 4
Header, TH,
100mil, 3x2, Gold
plated, 230 mil
above insulator
3x2 Header TSW-103-07-G-D Samtec
J49, J50 2
Header, TH,
100mil, 4x1, Gold
plated, 230 mil
above insulator
4x1 Header TSW-104-07-G-S Samtec
J54, J55, J63 3
Header, 100mil,
3x1, Gold, TH
3x1 Header TSW-103-07-G-S Samtec
J58 1
Header, 100mil,
6x1, Gold, TH
6x1 Header TSW-106-07-G-S Samtec
