Table 3. AFE5832 EVM Bill of Materials
(1)
(continued)
Designator Quantity Value Description
Package
Reference
PartNumber Manufacturer
Alternate
Part Number
Alternate
Manufacturer
R148, R171 2 3.30k
RES, 3.30 k, 1%,
0.1 W, AEC-Q200
Grade 0, 0402
0402 ERJ-2RKF3301X Panasonic
R149, R174 2 4.70k
RES, 4.70 k, 1%,
0.1 W, 0402
0402 ERJ-2RKF4701X Panasonic
R161, R162, R169,
R170
4 140k
RES, 140 k, 1%,
0.063 W, 0402
0402
CRCW0402140KF
KED
Vishay-Dale
R188, R189 2 0
RES, 0, 5%, 0.125
W, 0805
0805 MCR10EZPJ000 RΩ
S1, S2, S3, S4, S6 5
Switch, push-
button, SMD
2.9x2x3.9mm SMD SKRKAEE010 Alps
S5 1
Switch, SPST, 4
Pos, Top Actuated,
SMD
SMD, 8-Leads,
Pitch 1.27mm
1571983-5 TE Connectivity
SH-1, SH-2, SH-3,
SH-4, SH-5, SH-6
6 1x2
Shunt, 100mil,
Gold plated, Black
Shunt SNT-100-BK-G Samtec 969102-0000-DA 3M
T1, T2, T3, T4, T5 5
RF Transformer,
50 Ω, 2 to 775
MHz, SMT
CD542 ADT4-1WT+ Minicircuits
TP31, TP32, TP55,
TP62, TP63, TP64,
TP65, TP66, TP69
9 Black
Test Point,
Miniature, Black,
TH
Black Miniature
Testpoint
5001 Keystone
TP35 1 Yellow
Test Point,
Miniature, Yellow,
TH
Yellow Miniature
Testpoint
5004 Keystone
TP36, TP37, TP38,
TP39, TP49, TP50,
TP51, TP52
8 Orange
Test Point,
Miniature, Orange,
TH
Orange Miniature
Testpoint
5003 Keystone
TP48 1 Blue
Test Point,
Miniature, Blue, TH
Blue Miniature
Testpoint
5117 Keystone
TP53, TP56, TP57,
TP58, TP59, TP60,
TP68
7 Red
Test Point,
Miniature, Red, TH
Red Miniature
Testpoint
5000 Keystone
TP54, TP61, TP67 3 White
Test Point,
Miniature, White,
TH
White Miniature
Testpoint
5002 Keystone
