Texas Instruments bq78350-R1 Technical Reference

www.ti.com 0x00 ManufacturerAccess() and 0x44 ManufacturerBlockAccess()
107
SLUUBD3D–September 2015–Revised September 2018
Submit Documentation Feedback
Copyright © 2015–2018, Texas Instruments Incorporated
SBS Commands
Status Condition Action
Activate 0x0051 to ManufacturerAccess()
Outputs SafetyStatus() flags on
ManufacturerBlockAccess() or ManufacturerData()
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
RSVD RSVD RSVD RSVD RSVD RSVD RSVD RSVD RSVD RSVD RSVD OC RSVD CTO RSVD PTO
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
RSVD OCDL OTF
AFE_OV
RD
UTD UTC OTD OTC ASCDL ASCD AOLDL AOLD OCD OCC COV CUV
RSVD (Bits 31–21): Reserved
OC (Bit 20): Overcharge
1 = Detected
0 = Not Detected
RSVD (Bit 19): Reserved
CTO (Bit 18): Charge Timeout
1 = Detected
0 = Not Detected
RSVD (Bit 17): Reserved
PTO (Bit 16): Precharge Timeout
1 = Detected
0 = Not Detected
RSVD (Bits 15): Reserved
OCDL (Bit 14): Overcurrent During Discharge Latch
1 = Detected
0 = Not Detected
OTF (Bit 13): Overtemperature Fault
1 = Detected
0 = Not Detected
AFE_OVRD (Bit 12): AFE Alert
1 = Detected
0 = Not Detected
UTD (Bit 11): Undertemperature During Discharge
1 = Detected
0 = Not Detected
UTC (Bit 10): Undertemperature During Charge
1 = Detected
0 = Not Detected
OTD (Bit 9): Overtemperature During Discharge
1 = Detected
0 = Not Detected
OTC (Bit 8): Overtemperature During Charge
1 = Detected
0 = Not Detected
