Broadcasts to Smart Charger and Smart Battery Host
www.ti.com
94
SLUUBD3D–September 2015–Revised September 2018
Submit Documentation Feedback
Copyright © 2015–2018, Texas Instruments Incorporated
Communications
SMBA Pin Voltage
Channel VSMBAMIN Voltage (V) VSMBAMAX Voltage (V) Address Data Flash
0 0.070 0.130 SMBTAR_ADDR0
1 0.170 0.230 SMBTAR_ADDR1
2 0.270 0.330 SMBTAR_ADDR2
3 0.370 0.430 SMBTAR_ADDR3
4 0.470 0.530 SMBTAR_ADDR4
5 0.570 0.630 SMBTAR_ADDR5
6 0.670 0.730 SMBTAR_ADDR6
7 0.770 0.830 SMBTAR_ADDR7
0 All other values 0x16
If SMB Configuration [FIXED_ADDR] is set (1), then the slave address is 0x16/0x17 and the ADREN
and SMBA pins are ignored and not used.
NOTE: When determining the values for SMBTAR_ADDR0...7, take into account the R/W bit by
programming all addresses to even numbers.
Class Subclass Name Format
Size in
Bytes
Min Max Default Unit
Settings Configuration Addr Reads Integer 1 0 10 3 —
Settings Configuration SMBTAR_ADDR0 Integer 1 0x00 0xFE 0x20 —
Settings Configuration SMBTAR_ADDR1 Integer 1 0x00 0xFE 0x22 —
Settings Configuration SMBTAR_ADDR2 Integer 1 0x00 0xFE 0x24 —
Settings Configuration SMBTAR_ADDR3 Integer 1 0x00 0xFE 0x25 —
Settings Configuration SMBTAR_ADDR4 Integer 1 0x00 0xFE 0x26 —
Settings Configuration SMBTAR_ADDR5 Integer 1 0x00 0xFE 0x28 —
Settings Configuration SMBTAR_ADDR6 Integer 1 0x00 0xFE 0x2A —
Settings Configuration SMBTAR_ADDR7 Integer 1 0x00 0xFE 0x2C —
16.5 Broadcasts to Smart Charger and Smart Battery Host
If the [HPE] bit is enabled, MASTER mode broadcasts to the host address are PEC enabled. If the [CPE]
bit is enabled, MASTER mode broadcasts to the smart-charger address are PEC enabled. The [BCAST]
bit enables all broadcasts to a host or a smart charger. When the [BCAST] bit is enabled, the following
broadcasts are sent:
• ChargingVoltage() and ChargingCurrent() broadcasts are sent to the smart-charger device address
(Charger Address) periodically. The default period is set in Charger Request Timer.
• If any of the [OCA], [TCA], [OTA], [TDA], [RCA], [RTA] flags are set, the AlarmWarning() broadcast
is sent to the host device address (Host Address) at the period set in Alarm Timer. Broadcasts stop
when all flags above have been cleared.
• If any of the [OCA], [TCA], [OTA], [TDA] flags are set, the AlarmWarning() broadcast is sent to a
smart-charger device address (Charger Address) at the period set in Alarm Timer. Broadcasts stop
when all flags above have been cleared.
Class Subclass Name Format
Size in
Bytes
Min Max Default Unit
Settings
SMB Master
Mode
Host Address Integer 1 0x00 0xFE 10 —
Settings
SMB Master
Mode
Charger Address Integer 1 0x00 0xFE 12 —
Settings
SMB Master
Mode
Alarm Timer Integer 1 0 255 10 s
