Protections
3.1.2 Enabled Protections
Class Subclass Name Format
Size in
Bytes
Min Max Default Unit
Settings Protection
Enabled
Protections
A
Hex 1 0x00 0xFF 0xFF —
7 6 5 4 3 2 1 0
ASCDL ASCD AOLDL AOLD OCD OCC COV CUV
ASCDL (Bit 7): Short Circuit in Discharge Latch
0 = Disabled
1 = Enabled
ASCD (Bit 6): Short Circuit in Discharge recovery. Detection of an ASCD fault cannot be disabled.
0 = Bypassed, auto recovers within 250 ms
1 = Enabled
AOLDL (Bit 5): Overload in Discharge Latch
0 = Disabled
1 = Enabled
AOLD (Bit 4): Overload in Discharge recovery. Detection of an AOLD fault cannot be disabled.
0 = Bypassed, auto recovers within 250 ms
1 = Enabled
OCD (Bit 3): Overcurrent in Discharge
0 = Disabled
1 = Enabled
OCC (Bit 2): Overcurrent in Charge
0 = Disabled
1 = Enabled
COV (Bit 1): Cell Overvoltage
0 = Disabled
1 = Enabled
CUV (Bit 0): Cell Undervoltage
0 = Disabled
1 = Enabled
Class Subclass Name Format
Size in
Bytes
Min Max Default Unit
Settings Protection
Enabled
Protections
B
Hex 1 0x00 0xFF 0x0F —
