Texas Instruments bq78350-R1 Technical Reference

www.ti.com Introduction
19
SLUUBD3D–September 2015–Revised September 2018
Submit Documentation Feedback
Copyright © 2015–2018, Texas Instruments Incorporated
Protections
7 6 5 4 3 2 1 0
RSVD OCDL OTF AFE_OVRD UTD UTC OTD OTC
RSVD (Bit 7): Reserved
OCDL (Bit 6): Overcurrent in Discharge Latch
0 = Disabled (default)
1 = Enabled
OTF (Bit 5): Overtemperature Fault
0 = Disabled (default)
1 = Enabled
AFE_OVRD (Bit 4): AFE ALERT
0 = Disabled (default)
1 = Enabled
UTD (Bit 3): Undertemperature in Discharge
0 = Disabled
1 = Enabled
UTC (Bit 2): Undertemperature in Charge
0 = Disabled
1 = Enabled
OTD (Bit 1): Overtemperature in Discharge
0 = Disabled
1 = Enabled
OTC (Bit 0): Overtemperature in Charge
0 = Disabled
1 = Enabled
Class Subclass Name Format
Size in
Bytes
Min Max Default Unit
Settings Protection
Enabled
Protections
C
Hex 1 0x00 0xFF 0x15 —
7 6 5 4 3 2 1 0
RSVD RSVD RSVD OC CTOS CTO PTOS PTO
RSVD (Bits 7–5): Reserved. Do not use.
OC (Bit 4): Overcharge
0 = Disabled
1 = Enabled
CTOS (Bit 3): Charging Timeout Suspended
0 = Disabled
1 = Enabled
CTO (Bit 2): Charging Timeout
0 = Disabled
