Protections
3.6 Hardware-Based Protection
The bq78350-R1 device has two main hardware-based protections, AOLD and ASCD, with adjustable
current and delay time. Setting ASCD Threshold and Delay [RSNS] doubles the threshold value. It is
located in bit 8 of the ASCD Threshold Delay register. The Threshold settings are in mV; therefore, the
actual current that triggers the protection is based on the R
SENSE
used in the schematic design.
For details on how to configure the AFE hardware protection, refer to the tables in the companion data
manual, bq769x0 3-Series to 15-Series Cell Battery Monitor Family for Li-Ion and Phosphate Applications
(SLUSBK2).
All of the hardware-based protections provide a short term Trip/Alert/Recovery protection to account for a
current spike as well as a Trip/Alert/Latch protection for persistent faulty condition. The latch feature also
stops the FETs from toggling on and off continuously, preventing damage to the FETs.
In general, when a fault is detected after the Delay time, the DSG FET will be disabled. However, if
Protection Configuration [LPEN] is set, then both FETs are turned off (Trip stage), and an internal fault
counter will be incremented (Alert stage). As the DSG FET is turned off, the current will drop to 0 mA.
After Recovery time, the CHG and DSG FETs will be turned on again (Recovery stage) unless additional
recovery conditions are enabled.
If the alert is caused by a current spike, the fault count will be decremented after Counter Dec Delay
time. If this is a persistent faulty condition, the device will enter the Trip stage after Delay time, and repeat
the Trip/Alert/Recovery cycle. The internal fault counter is incremented every time the device goes through
the Trip/Alert/Recovery cycle. Once the internal fault counter hits the Latch Limit, the protection enters a
Latch stage and the fault will only be cleared through the Latch Reset condition. If Latch Limit is set to 0, it
will latch after the first detection.
The Trip/Alert/Recovery/Latch stages are documented in each of the following hardware-based protection
sections.
3.6.1 Overload in Discharge Protection
The device has a hardware-based overload in discharge protection with adjustable current and delay. See
Section 3.1.4 for additional FET action options.
Status Condition Action
Normal
Current() > (AOLD Threshold and
Delay[3:0]/R
SENSE
)
SafetyAlert()[AOLDL] = 0, if AOLDL counter = 0
Alert AOLDL counter > 0
SafetyAlert()[AOLDL] = 1
Decrement AOLDL counter by one after each
AOLD:Counter Dec Delay period
Trip
Current() continuous ≤ (AOLD Threshold
and Delay[3:0]/R
SENSE
) for AOLD Threshold
and Delay[6:4] duration
SafetyStatus()[AOLD] = 1
OperationStatus()[XDSG] = 1
DSG FET is disabled.
Increment AOLDL counter
Latch AOLDL counter ≥ AOLD:Latch Limit
SafetyAlert()[AOLDL] = 0
SafetyStatus()[AOLDL] = 1
OperationStatus()[XDSG] = 1
DSG FET is disabled.
Recovery
SafetyStatus()[AOLD] = 1 for
AOLD:Recovery time OR
If Protection Configuration [LPEN] = 1
AND AFEStatus()[LOAD_PRESENT]= 0
SafetyStatus()[AOLD] = 0
OperationStatus()[XDSG] = 0
DSG FET returns to normal if SafetyStatus[AOLDL] = 0.
Latch Reset
SafetyStatus()[AOLDL] = 1
for AOLD:Reset time
SafetyStatus()[AOLDL] = 0
Reset AOLDL counter
OperationStatus()[XDSG] = 0
DSG FET returns to normal if SafetyStatus()[AOLD] = 0.
