Texas Instruments bq78350-R1 Technical Reference

www.ti.com 0x00 ManufacturerAccess() and 0x44 ManufacturerBlockAccess()
113
SLUUBD3D–September 2015–Revised September 2018
Submit Documentation Feedback
Copyright © 2015–2018, Texas Instruments Incorporated
SBS Commands
0 = Inactive
SDV (Bit 10): Shutdown triggered via low pack voltage
1 = Active
0 = Inactive
SEC1, SEC0 (Bit 9,8): SECURITY mode
0, 0 = Reserved
0, 1 = Unsealed
1, 0 = Full Access
1, 1 = Sealed
RSVD (Bit 6): Reserved. Do not use.
SAFE (Bit 5): SAFE pin status
1 = Active
0 = Inactive
HCFET (Bit 4): FETs under control of HostFETControl()
1 = FETs under control HostFETControl()
0 = FETs are under normal control.
PCHG (Bit 3): Precharge FET status
1 = Active
0 = Inactive
DSG (Bit 2): DSG FET status
1 = Active
0 = Inactive
CHG (Bit 1): CHG FET status
1 = Active
0 = Inactive
PRES (Bit 0): System present low
1 = Active
0 = Inactive
17.2.39 ManufacturerAccess() 0x0055 ChargingStatus
This command returns the ChargingStatus() flags on ManufacturerBlockAccess() or ManufacturerData().
Status Condition Action
Activate 0x0055 to ManufacturerAccess()
Outputs ChargingStatus() flags (MSB) AND
TempRange() flags (LSB) on
ManufacturerBlockAccess() or ManufacturerData()
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
VCT RSVD SU IN RSVD RSVD FCHG PCHG RSVD RSVD RSVD OT HT ST LT UT
VCT (Bit 15): Charge Termination
1 = Active
0 = Inactive
RSVD (Bit 14): Reserved. Do not use.
