0x00 ManufacturerAccess() and 0x44 ManufacturerBlockAccess()
www.ti.com
110
SLUUBD3D–September 2015–Revised September 2018
Submit Documentation Feedback
Copyright © 2015–2018, Texas Instruments Incorporated
SBS Commands
Status Condition Action
Activate 0x0053 to ManufacturerAccess()
Outputs PFStatus() flags on
ManufacturerBlockAccess() or ManufacturerData()
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
RSVD RSVD RSVD RSVD RSVD RSVD RSVD RSVD RSVD RSVD RSVD RSVD RSVD RSVD DFW IFC
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
SOTF TS3 TS2 TS1
AFE_
XRDY
AFE_
OVRD
AFEC AFER DFETF CFETF VIMR SOT SOCD SOCC SOV SUV
RSVD (Bit 31–18): Reserved. Do not use.
DFW (Bit 17): Data Flash Wearout Failure
1 = Detected
0 = Not Detected
IFC (Bit 16): Instruction Flash Checksum Failure
1 = Detected
0 = Not Detected
SOTF (Bit 15): Safety Overtemperature FET Failure
1 = Detected
0 = Not Detected
TS3 (Bit 14): Open Thermistor – TS3 Failure
1 = Detected
0 = Not Detected
TS2 (Bit 13): Open Thermistor – TS2 Failure
1 = Detected
0 = Not Detected
TS1 (Bit 12): Open Thermistor – TS1 Failure
1 = Detected
0 = Not Detected
AFE_XRDY (Bit 11): Companion bq769x0 AFE XREADY Failure
1 = Detected
0 = Not Detected
AFE_OVRD (Bit 10): Companion bq769x0 AFE Override Failure
1 = Detected
0 = Not Detected
AFEC (Bit 9): AFE Communication Failure
1 = Detected
0 = Not Detected
AFER (Bit 8): AFE Register Failure
1 = Detected
0 = Not Detected
DFETF (Bit 7): Discharge FET Failure
1 = Detected
0 = Not Detected
CFETF (Bit 6): Charge FET Failure
