Data Flash Summary
Chapter 19
SLUUBD3D–September 2015–Revised September 2018
Data Flash Summary
Table 19-1. Data Flash Summary Table
Class Subclass Address Name Type Min Value Max Value Default Units
Calibration Current 0x4000 CC Gain F4 1.00E–01 9.00E+00 8.4381 —
Calibration Current 0x4004 Capacity Gain F4 2.98262E+04 2.693046E+07 2516761.36 —
Calibration Voltage 0x4008 Cell1 Offset I1 –128 127 0 mV
Calibration Voltage 0x4009 Cell2 Offset I1 –128 127 0 mV
Calibration Voltage 0x400A Cell3 Offset I1 –128 127 0 mV
Calibration Voltage 0x400B Cell4 Offset I1 –128 127 0 mV
Calibration Voltage 0x400C Cell5 Offset I1 –128 127 0 mV
Calibration Voltage 0x400D Cell6 Offset I1 –128 127 0 mV
Calibration Voltage 0x400E Cell7 Offset I1 –128 127 0 mV
Calibration Voltage 0x400F Cell8 Offset I1 –128 127 0 mV
Calibration Voltage 0x4010 Cell9 Offset I1 –128 127 0 mV
Calibration Voltage 0x4011 Cell10 Offset I1 –128 127 0 mV
Calibration Voltage 0x4012 Cell11 Offset I1 –128 127 0 mV
Calibration Voltage 0x4013 Cell12 Offset I1 –128 127 0 mV
Calibration Voltage 0x4014 Cell13 Offset I1 –128 127 0 mV
Calibration Voltage 0x4015 Cell14 Offset I1 –128 127 0 mV
Calibration Voltage 0x4016 Cell15 Offset I1 –128 127 0 mV
Calibration Current Offset 0x4018 CC Offset I2 –32767 32767 0 —
Calibration Current Offset 0x401A
Coulomb Counter Offset
Samples
U2 0 65535 64 —
Calibration Temperature 0x401E T1 Temp Offset I1 –128 127 0 0.1°C
Calibration Temperature 0x401F T2 Temp Offset I1 –128 127 0 0.1°C
Calibration Temperature 0x4020 T3 Temp Offset I1 –128 127 0 0.1°C
Calibration Temperature 0x4021
Gauge Internal Temp
Offset
I1 –128 127 0 0.1°C
Calibration
Ext Cell
Voltage
0x4022 Ext Cell Divider Gain I2 0 32767 5000 —
Calibration VAux Voltage 0x4024 VAux Gain I4 0 100000 5000 —
Calibration
Cell
Temperature
Model
0x454F Coeff a1 I2 –32768 32767 –11130 —
Calibration
Cell
Temperature
Model
0x4551 Coeff a2 I2 –32768 32767 19142 —
Calibration
Cell
Temperature
Model
0x4553 Coeff a3 I2 –32768 32767 –19262 —
Calibration
Cell
Temperature
Model
0x4555 Coeff a4 I2 –32768 32767 28203 —
Calibration
Cell
Temperature
Model
0x4557 Coeff a5 I2 –32768 32767 892 —
Calibration
Cell
Temperature
Model
0x4559 Coeff b1 I2 –32768 32767 328 —
