Data Flash Summary
Table 19-1. Data Flash Summary Table (continued)
Class Subclass Address Name Type Min Value Max Value Default Units
SBS
Configuration
Data 0x4084 Device Name S21 x x bq78350 —
SBS
Configuration
Data 0x4099 Device Chemistry S5 x x LION —
SBS
Configuration
Data 0x449F
Remaining AH Cap.
Alarm
I2 0 32767 300 mAh
SBS
Configuration
Data 0x44A1
Remaining WH Cap.
Alarm
I2 0 32767 432 cWh
SBS
Configuration
Data 0x44A3 Remaining Time Alarm U2 0 65535 10 min
SBS
Configuration
Data 0x44A5 Initial Battery Mode H2 0x0 0xFFFF 0x0081 Hex
SBS
Configuration
Data 0x44A7 Specification Information H2 0x0 0xFFFF 0x0031 Hex
LED Support LED Config 0x448D LED Flash Period U2 32 65535 512 488 μs
LED Support LED Config 0x448F LED Blink Period U2 32 65535 1024 488 μs
LED Support LED Config 0x4491 LED Delay U2 16 65535 100 488 μs
LED Support LED Config 0x4493 LED Hold Time U1 1 63 16 0.25 s
LED Support LED Config 0x4494 LED Flash Alarm I1 0 100 10 %
LED Support LED Config 0x4495 LED Thresh 1 I1 0 100 0 %
LED Support LED Config 0x4496 LED Thresh 2 I1 0 100 20 %
LED Support LED Config 0x4497 LED Thresh 3 I1 0 100 40 %
LED Support LED Config 0x4498 LED Thresh 4 I1 0 100 60 %
LED Support LED Config 0x4499 LED Thresh 5 I1 0 100 80 %
LED Support LED Config 0x449A LCD Refresh Rate U1 20 100 35 Hz
Lifetimes Voltage 0x40C0 Cell 1 Max Voltage I2 0 32767 0 mV
Lifetimes Voltage 0x40C2 Cell 2 Max Voltage I2 0 32767 0 mV
Lifetimes Voltage 0x40C4 Cell 3 Max Voltage I2 0 32767 0 mV
Lifetimes Voltage 0x40C6 Cell 4 Max Voltage I2 0 32767 0 mV
Lifetimes Voltage 0x40C8 Cell 5 Max Voltage I2 0 32767 0 mV
Lifetimes Voltage 0x40CA Cell 6 Max Voltage I2 0 32767 0 mV
Lifetimes Voltage 0x40CC Cell 7 Max Voltage I2 0 32767 0 mV
Lifetimes Voltage 0x40CE Cell 8 Max Voltage I2 0 32767 0 mV
Lifetimes Voltage 0x40D0 Cell 9 Max Voltage I2 0 32767 0 mV
Lifetimes Voltage 0x40D2 Cell 10 Max Voltage I2 0 32767 0 mV
Lifetimes Voltage 0x40D4 Cell 11 Max Voltage I2 0 32767 0 mV
Lifetimes Voltage 0x40D6 Cell 12 Max Voltage I2 0 32767 0 mV
Lifetimes Voltage 0x40D8 Cell 13 Max Voltage I2 0 32767 0 mV
Lifetimes Voltage 0x40DA Cell 14 Max Voltage I2 0 32767 0 mV
Lifetimes Voltage 0x40DC Cell 15 Max Voltage I2 0 32767 0 mV
Lifetimes Voltage 0x40E0 Cell 1 Min Voltage I2 0 32767 32767 mV
Lifetimes Voltage 0x40E2 Cell 2 Min Voltage I2 0 32767 32767 mV
Lifetimes Voltage 0x40E4 Cell 3 Min Voltage I2 0 32767 32767 mV
Lifetimes Voltage 0x40E6 Cell 4 Min Voltage I2 0 32767 32767 mV
Lifetimes Voltage 0x40E8 Cell 5 Min Voltage I2 0 32767 32767 mV
Lifetimes Voltage 0x40EA Cell 6 Min Voltage I2 0 32767 32767 mV
Lifetimes Voltage 0x40EC Cell 7 Min Voltage I2 0 32767 32767 mV
Lifetimes Voltage 0x40EE Cell 8 Min Voltage I2 0 32767 32767 mV
Lifetimes Voltage 0x40F0 Cell 9 Min Voltage I2 0 32767 32767 mV
Lifetimes Voltage 0x40F2 Cell 10 Min Voltage I2 0 32767 32767 mV
Lifetimes Voltage 0x40F4 Cell 11 Min Voltage I2 0 32767 32767 mV
Lifetimes Voltage 0x40F6 Cell 12 Min Voltage I2 0 32767 32767 mV
Lifetimes Voltage 0x40F8 Cell 13 Min Voltage I2 0 32767 32767 mV
Lifetimes Voltage 0x40FA Cell 14 Min Voltage I2 0 32767 32767 mV
