LMX2572EVM Evaluation Instructions
6 Bill of Materials
Table 6. Bill of Materials
DESIGNATOR QUANTITY DESCRIPTION PART NUMBER MANUFACTURER
C1, C3, C9, C14, C15, C17, C30 7 CAP, CERM, 0.1 µF, 16 V, ±5%, X7R,
0603
0603YC104JAT2A AVX
C2, C4, C8, C16 4 CAP, CERM, 10 µF, 10 V, ±10%, X5R,
0805
C0805C106K8PACTU Kemet
C2_LF 1 CAP, CERM, 0.015 µF, 50 V, ±10%,
X7R, 0603
GRM188R71H153KA01D MuRata
C4_LF 1 CAP, CERM, 2200 pF, 50 V, ±5%,
C0G/NP0, 0603
GRM1885C1H222JA01D MuRata
C5, C7, C10, C12 4 CAP, CERM, 0.01 µF, 16 V, ±10%, X7R,
0402
520L103KT16T AT Ceramics
C18, C23, C24, C26, C27, C28, C29 7 CAP, CERM, 1 µF, 16 V, ±10%, X7R,
0603
C1608X7R1C105K080AC TDK
C19, C20, C21, C22, C25 5 CAP, CERM, 10 µ F, 10 V, ±20%, X5R,
0603
C1608X5R1A106M080AC TDK
CE_TP, CSB_TP, GND_TP,
MUXout_TP, RampCLK_TP,
RampDIR_TP, SCK_TP, SDI_TP,
SYNC_TP, SysRefReq_TP, Vcc_TP,
VccRF_TP, Vtune_TP
13 Test Point, Compact, White, TH 5007 Keystone
Cin_0 1 CAP, CERM, 10 µF, 25 V, ±10%, X5R,
0805
GRM219R61E106KA12D MuRata
Cout0 1 CAP, CERM, 22 µF, 16 V, ±10%, X5R,
0805
C2012X5R1C226K125AC TDK
Css 1 CAP, CERM, 3300 pF, 50 V, ±5%,
C0G/NP0, 0603
GRM1885C1H332JA01D MuRata
D1 1 LED, Green, SMD LTST-C190GKT Lite-On
L1_TPS 1 Inductor, Shielded, Composite, 2.2 µH,
3.7 A, 0.02 Ω, SMD
XFL4020-222MEB Coilcraft
MUXout_SW 1 Switch, SPST, Slide, Off-On, 2 Pos, 0.1
A, 20 V, SMD
219-2MST CTS
Electrocomponents
OSCinM, OSCinP, SYNC, SysRef, Vcc 5 Connector, SMT, End launch SMA 50 Ω 142-0701-851 Emerson Network
Power Connectivity
R1 1 RES, 330 Ω, 5%, 0.1 W, 0603 RC0603JR-07330RL Yageo America
R2 1 RES, 100 kΩ, 5%, 0.1 W, 0603 CRCW0603100KJNEA Vishay-Dale
R2_LF 1 RES, 330 Ω, 5%, 0.1 W, 0603 CRCW0603330RJNEA Vishay-Dale
R3_LF, R4_LF, R12, R15, R24, R26,
R31
7 RES, 0 Ω, 5%, 0.1 W, 0603 CRCW06030000Z0EA Vishay-Dale
R5, R7, R8, R9, R16, R19, R20, R22 8 RES, 12 kΩ, 5%, 0.1 W, 0603 CRCW060312K0JNEA Vishay-Dale
R25, R30 2 RES, 51 Ω, 5%, 0.1 W, 0603 CRCW060351R0JNEA Vishay-Dale
R34, R35, R36, R41, R42, R43, R44,
R45
8 RES, 0 Ω, 5%, 0.1 W, 0603 CRCW06030000Z0EA Vishay-Dale
Rfbb1 1 RES, 180 kΩ, 0.1%, 0.1 W, 0603 RT0603BRD07180KL Yageo America
Rfbt1 1 RES, 562 kΩ, 1%, 0.1 W, 0603 CRCW0603562KFKEA Vishay-Dale
RFoutAM, RFoutAP, RFoutBM, RFoutBP 4 JACK, SMA, 50 Ω, Gold, Edge Mount 142-0771-831 Johnson
U1 1 High Performance, Wideband PLLatinum
RF Synthesizer
LMX2572RHAR Texas Instruments
uWire 1 Header (shrouded), 100 mil, 5x2, Gold
plated, SMD
52601-S10-8LF FCI
