(1) Registers that are EALLOW protected.
Table 6-56. ePWM1–ePWM4 Control and Status Registers
NAME ePWM1 ePWM2 ePWM3 ePWM4
SIZE (× 16)/
#SHADOW
DESCRIPTION
TBCTL 0x6800 0x6840 0x6880 0x68C0 1/0 Time Base Control Register
TBSTS 0x6801 0x6841 0x6881 0x68C1 1/0 Time Base Status Register
TBPHSHR 0x6802 0x6842 0x6882 0x68C2 1/0 Time Base Phase HRPWM Register
TBPHS 0x6803 0x6843 0x6883 0x68C3 1/0 Time Base Phase Register
TBCTR 0x6804 0x6844 0x6884 0x68C4 1/0 Time Base Counter Register
TBPRD 0x6805 0x6845 0x6885 0x68C5 1/1 Time Base Period Register Set
TBPRDHR 0x6806 0x6846 0x6886 0x68C6 1/1 Time Base Period High-Resolution Register
(1)
CMPCTL 0x6807 0x6847 0x6887 0x68C7 1/0 Counter Compare Control Register
CMPAHR 0x6808 0x6848 0x6888 0x68C8 1/1 Time Base Compare A HRPWM Register
CMPA 0x6809 0x6849 0x6889 0x68C9 1/1 Counter Compare A Register Set
CMPB 0x680A 0x684A 0x688A 0x68CA 1/1 Counter Compare B Register Set
AQCTLA 0x680B 0x684B 0x688B 0x68CB 1/0 Action Qualifier Control Register For Output A
AQCTLB 0x680C 0x684C 0x688C 0x68CC 1/0 Action Qualifier Control Register For Output B
AQSFRC 0x680D 0x684D 0x688D 0x68CD 1/0 Action Qualifier Software Force Register
AQCSFRC 0x680E 0x684E 0x688E 0x68CE 1/1 Action Qualifier Continuous S/W Force Register Set
DBCTL 0x680F 0x684F 0x688F 0x68CF 1/1 Dead-Band Generator Control Register
DBRED 0x6810 0x6850 0x6890 0x68D0 1/0 Dead-Band Generator Rising Edge Delay Count Register
DBFED 0x6811 0x6851 0x6891 0x68D1 1/0 Dead-Band Generator Falling Edge Delay Count Register
TZSEL 0x6812 0x6852 0x6892 0x68D2 1/0 Trip Zone Select Register
(1)
TZDCSEL 0x6813 0x6853 0x6893 0x68D3 1/0 Trip Zone Digital Compare Register
TZCTL 0x6814 0x6854 0x6894 0x68D4 1/0 Trip Zone Control Register
(1)
TZEINT 0x6815 0x6855 0x6895 0x68D5 1/0 Trip Zone Enable Interrupt Register
(1)
TZFLG 0x6816 0x6856 0x6896 0x68D6 1/0 Trip Zone Flag Register
(1)
TZCLR 0x6817 0x6857 0x6897 0x68D7 1/0 Trip Zone Clear Register
(1)
TZFRC 0x6818 0x6858 0x6898 0x68D8 1/0 Trip Zone Force Register
(1)
ETSEL 0x6819 0x6859 0x6899 0x68D9 1/0 Event Trigger Selection Register
ETPS 0x681A 0x685A 0x689A 0x68DA 1/0 Event Trigger Prescale Register
ETFLG 0x681B 0x685B 0x689B 0x68DB 1/0 Event Trigger Flag Register
ETCLR 0x681C 0x685C 0x689C 0x68DC 1/0 Event Trigger Clear Register
ETFRC 0x681D 0x685D 0x689D 0x68DD 1/0 Event Trigger Force Register
PCCTL 0x681E 0x685E 0x689E 0x68DE 1/0 PWM Chopper Control Register
HRCNFG 0x6820 0x6860 0x68A0 0x68E0 1/0 HRPWM Configuration Register
(1)
