Table 6-56. ePWM1–ePWM4 Control and Status Registers (continued)
NAME ePWM1 ePWM2 ePWM3 ePWM4
SIZE (× 16)/
#SHADOW
DESCRIPTION
(2) W = Write to shadow register
HRMSTEP 0x6826 - - - 1/0 HRPWM MEP Step Register
HRPCTL 0x6828 0x6868 0x68A8 0x68E8 1/0 High-resolution Period Control Register
(1)
TBPRDHRM 0x682A 0x686A 0x68AA 0x68EA 1/W
(2)
Time Base Period HRPWM Register Mirror
TBPRDM 0x682B 0x686B 0x68AB 0x68EB 1/W
(2)
Time Base Period Register Mirror
CMPAHRM 0x682C 0x686C 0x68AC 0x68EC 1/W
(2)
Compare A HRPWM Register Mirror
CMPAM 0x682D 0x686D 0x68AD 0x68ED 1/W
(2)
Compare A Register Mirror
DCTRIPSEL 0x6830 0x6870 0x68B0 0x68F0 1/0 Digital Compare Trip Select Register
(1)
DCACTL 0x6831 0x6871 0x68B1 0x68F1 1/0 Digital Compare A Control Register
(1)
DCBCTL 0x6832 0x6872 0x68B2 0x68F2 1/0 Digital Compare B Control Register
(1)
DCFCTL 0x6833 0x6873 0x68B3 0x68F3 1/0 Digital Compare Filter Control Register
(1)
DCCAPCT 0x6834 0x6874 0x68B4 0x68F4 1/0 Digital Compare Capture Control Register
(1)
DCFOFFSET 0x6835 0x6875 0x68B5 0x68F5 1/1 Digital Compare Filter Offset Register
DCFOFFSETCNT 0x6836 0x6876 0x68B6 0x68F6 1/0 Digital Compare Filter Offset Counter Register
DCFWINDOW 0x6837 0x6877 0x68B7 0x68F7 1/0 Digital Compare Filter Window Register
DCFWINDOWCNT 0x6838 0x6878 0x68B8 0x68F8 1/0 Digital Compare Filter Window Counter Register
DCCAP 0x6839 0x6879 0x68B9 0x68F9 1/1 Digital Compare Counter Capture Register
(1) Registers that are EALLOW protected.
Table 6-57. ePWM5–ePWM8 Control and Status Registers
NAME ePWM5 ePWM6 ePWM7 ePWM8
SIZE (× 16)/
#SHADOW
DESCRIPTION
TBCTL 0x6900 0x6940 0x6980 0x69C0 1/0 Time Base Control Register
TBSTS 0x6901 0x6941 0x6981 0x69C1 1/0 Time Base Status Register
TBPHSHR 0x6902 0x6942 0x6982 0x69C2 1/0 Time Base Phase HRPWM Register
TBPHS 0x6903 0x6943 0x6983 0x69C3 1/0 Time Base Phase Register
TBCTR 0x6904 0x6944 0x6984 0x69C4 1/0 Time Base Counter Register
TBPRD 0x6905 0x6945 0x6985 0x69C5 1/1 Time Base Period Register Set
TBPRDHR 0x6906 0x6946 0x6986 0x69C6 1/1 Time Base Period High-Resolution Register
(1)
CMPCTL 0x6907 0x6947 0x6987 0x69C7 1/0 Counter Compare Control Register
CMPAHR 0x6908 0x6948 0x6988 0x69C8 1/1 Time Base Compare A HRPWM Register
CMPA 0x6909 0x6949 0x6989 0x69C9 1/1 Counter Compare A Register Set
CMPB 0x690A 0x694A 0x698A 0x69CA 1/1 Counter Compare B Register Set
