Table 6-57. ePWM5–ePWM8 Control and Status Registers (continued)
NAME ePWM5 ePWM6 ePWM7 ePWM8
SIZE (× 16)/
#SHADOW
DESCRIPTION
(2) W = Write to shadow register
AQCTLA 0x690B 0x694B 0x698B 0x69CB 1/0 Action Qualifier Control Register For Output A
AQCTLB 0x690C 0x694C 0x698C 0x69CC 1/0 Action Qualifier Control Register For Output B
AQSFRC 0x690D 0x694D 0x698D 0x69CD 1/0 Action Qualifier Software Force Register
AQCSFRC 0x690E 0x694E 0x698E 0x69CE 1/1 Action Qualifier Continuous S/W Force Register Set
DBCTL 0x690F 0x694F 0x698F 0x69CF 1/1 Dead-Band Generator Control Register
DBRED 0x6910 0x6950 0x6990 0x69D0 1/0 Dead-Band Generator Rising Edge Delay Count Register
DBFED 0x6911 0x6951 0x6991 0x69D1 1/0 Dead-Band Generator Falling Edge Delay Count Register
TZSEL 0x6912 0x6952 0x6992 0x69D2 1/0 Trip Zone Select Register
(1)
TZDCSEL 0x6913 0x6953 0x6993 0x69D3 1/0 Trip Zone Digital Compare Register
TZCTL 0x6914 0x6954 0x6994 0x69D4 1/0 Trip Zone Control Register
(1)
TZEINT 0x6915 0x6955 0x6995 0x69D5 1/0 Trip Zone Enable Interrupt Register
(1)
TZFLG 0x6916 0x6956 0x6996 0x69D6 1/0 Trip Zone Flag Register
(1)
TZCLR 0x6917 0x6957 0x6997 0x69D7 1/0 Trip Zone Clear Register
(1)
TZFRC 0x6918 0x6958 0x6998 0x69D8 1/0 Trip Zone Force Register
(1)
ETSEL 0x6919 0x6959 0x6999 0x69D9 1/0 Event Trigger Selection Register
ETPS 0x691A 0x695A 0x699A 0x69DA 1/0 Event Trigger Prescale Register
ETFLG 0x691B 0x695B 0x699B 0x69DB 1/0 Event Trigger Flag Register
ETCLR 0x691C 0x695C 0x699C 0x69DC 1/0 Event Trigger Clear Register
ETFRC 0x691D 0x695D 0x699D 0x69DD 1/0 Event Trigger Force Register
PCCTL 0x691E 0x695E 0x699E 0x69DE 1/0 PWM Chopper Control Register
HRCNFG 0x6920 0x6960 0x69A0 0x69E0 1/0 HRPWM Configuration Register
(1)
HRMSTEP - - - - 1/0 HRPWM MEP Step Register
HRPCTL 0x6928 0x6968 0x69A8 0x69E8 1/0 High-resolution Period Control Register
(1)
TBPRDHRM 0x692A 0x696A 0x69AA 0x69EA 1/W
(2)
Time Base Period HRPWM Register Mirror
TBPRDM 0x692B 0x696B 0x69AB 0x69EB 1/W
(2)
Time Base Period Register Mirror
CMPAHRM 0x692C 0x696C 0x69AC 0x69EC 1/W
(2)
Compare A HRPWM Register Mirror
CMPAM 0x692D 0x696D 0x69AD 0x69ED 1/W
(2)
Compare A Register Mirror
DCTRIPSEL 0x6930 0x6970 0x69B0 0x69F0 1/0 Digital Compare Trip Select Register
(1)
DCACTL 0x6931 0x6971 0x69B1 0x69F1 1/0 Digital Compare A Control Register
(1)
DCBCTL 0x6932 0x6972 0x69B2 0x69F2 1/0 Digital Compare B Control Register
(1)
DCFCTL 0x6933 0x6973 0x69B3 0x69F3 1/0 Digital Compare Filter Control Register
(1)
DCCAPCT 0x6934 0x6974 0x69B4 0x69F4 1/0 Digital Compare Capture Control Register
(1)
