Table 6-57. ePWM5–ePWM8 Control and Status Registers (continued)
NAME ePWM5 ePWM6 ePWM7 ePWM8
SIZE (× 16)/
#SHADOW
DESCRIPTION
DCFOFFSET 0x6935 0x6975 0x69B5 0x69F5 1/1 Digital Compare Filter Offset Register
DCFOFFSETCNT 0x6936 0x6976 0x69B6 0x69F6 1/0 Digital Compare Filter Offset Counter Register
DCFWINDOW 0x6937 0x6977 0x69B7 0x69F7 1/0 Digital Compare Filter Window Register
DCFWINDOWCNT 0x6938 0x6978 0x69B8 0x69F8 1/0 Digital Compare Filter Window Counter Register
DCCAP 0x6939 0x6979 0x69B9 0x69F9 1/1 Digital Compare Counter Capture Register
