6.9.16 Universal Serial Bus (USB)
6.9.16.1 USB Electrical Data/Timing
Table 6-83. USB Input Ports DP and DM Timing Requirements
V
CC
MIN MAX UNIT
V(CM) Differential input common mode range 0.8 2.5 V
Z(IN) Input impedance 300 kΩ
VCRS Crossover voltage 1.3 2.0 V
V
IL
Static SE input logic-low level 0.8 V
V
IH
Static SE input logic-high level 2.0 V
VDI Differential input voltage 0.2 V
Table 6-84. USB Output Ports DP and DM Switching Characteristics
over recommended operating conditions (unless otherwise noted)
PARAMETER TEST CONDITIONS V
CC
MIN MAX UNIT
V
OH
D+, D– single-ended USB 2.0 load conditions 2.8 3.6 V
V
OL
D+, D– single-ended USB 2.0 load conditions 0 0.3 V
Z(DRV) D+, D– impedance 28 44 Ω
t
r
Rise time
Full speed, differential, C
L
= 50 pF,
10%/90%, Rpu on D+
4 20 ns
t
f
Fall time
Full speed, differential, C
L
= 50 pF,
10%/90%, Rpu on D+
4 20 ns
