TMS320F28069 , TMS320F28068 , TMS320F28067 , TMS320F28066
TMS320F28065, TMS320F28064, TMS320F28063, TMS320F28062
SPRS698F –NOVEMBER 2010–REVISED MARCH 2016 www.ti.com
Submit Documentation Feedback
Product Folder Links: TMS320F28069 TMS320F28068 TMS320F28067 TMS320F28066 TMS320F28065
TMS320F28064 TMS320F28063 TMS320F28062
Specifications Copyright © 2010–2016, Texas Instruments Incorporated
(1) These values are based on a JEDEC-defined 2S2P system (with the exception of the Theta JC [RΘ
JC
] value, which is based on a
JEDEC-defined 1S0P system) and will change based on environment as well as application. For more information, see these
EIA/JEDEC standards:
• JESD51-2, Integrated Circuits Thermal Test Method Environmental Conditions - Natural Convection (Still Air)
• JESD51-3, Low Effective Thermal Conductivity Test Board for Leaded Surface Mount Packages
• JESD51-7, High Effective Thermal Conductivity Test Board for Leaded Surface Mount Packages
• JESD51-9, Test Boards for Area Array Surface Mount Package Thermal Measurements
(2) lfm = linear feet per minute
5.7.3 PN Package
°C/W
(1)
AIR FLOW (lfm)
(2)
RΘ
JC
Junction-to-case thermal resistance 7.9 0
RΘ
JB
Junction-to-board thermal resistance 15.6 0
RΘ
JA
(High k PCB)
Junction-to-free air thermal resistance
41.1 0
31.2 150
29.7 250
27.5 500
Psi
JT
Junction-to-package top
0.4 0
0.6 150
0.7 250
0.9 500
Psi
JB
Junction-to-board
15.3 0
14.6 150
14.4 250
14.1 500
(1) These values are based on a JEDEC-defined 2S2P system (with the exception of the Theta JC [RΘ
JC
] value, which is based on a
JEDEC-defined 1S0P system) and will change based on environment as well as application. For more information, see these
EIA/JEDEC standards:
• JESD51-2, Integrated Circuits Thermal Test Method Environmental Conditions - Natural Convection (Still Air)
• JESD51-3, Low Effective Thermal Conductivity Test Board for Leaded Surface Mount Packages
• JESD51-7, High Effective Thermal Conductivity Test Board for Leaded Surface Mount Packages
• JESD51-9, Test Boards for Area Array Surface Mount Package Thermal Measurements
(2) lfm = linear feet per minute
5.7.4 PZ Package
°C/W
(1)
AIR FLOW (lfm)
(2)
RΘ
JC
Junction-to-case thermal resistance 7.2 0
RΘ
JB
Junction-to-board thermal resistance 19.6 0
RΘ
JA
(High k PCB)
Junction-to-free air thermal resistance
42.2 0
32.4 150
30.9 250
28.7 500
Psi
JT
Junction-to-package top
0.4 0
0.6 150
0.7 250
0.9 500
Psi
JB
Junction-to-board
19.1 0
18.2 150
17.9 250
14.1 500
