Table 6-3. Addresses of Flash Sectors in F28069, F28068, F28067, F28066
ADDRESS RANGE PROGRAM AND DATA SPACE
0x3D 8000 – 0x3D BFFF Sector H (16K × 16)
0x3D C000 – 0x3D FFFF Sector G (16K × 16)
0x3E 0000 – 0x3E 3FFF Sector F (16K × 16)
0x3E 4000 – 0x3E 7FFF Sector E (16K × 16)
0x3E 8000 – 0x3E BFFF Sector D (16K × 16)
0x3E C000 – 0x3E FFFF Sector C (16K × 16)
0x3F 0000 – 0x3F 3FFF Sector B (16K × 16)
0x3F 4000 – 0x3F 7FF5 Sector A (16K × 16)
0x3F 7FF6 – 0x3F 7FF7
Boot-to-Flash Entry Point
(program branch instruction here)
0x3F 7FF8 – 0x3F 7FFF
Security Password (128-Bit)
(Do not program to all zeros)
Table 6-4. Addresses of Flash Sectors in F28065, F28064, F28063, F28062
ADDRESS RANGE PROGRAM AND DATA SPACE
0x3E 8000 – 0x3E 9FFF Sector H (8K × 16)
0x3E A000 – 0x3E BFFF Sector G (8K × 16)
0x3E C000 – 0x3E DFFF Sector F (8K × 16)
0x3E E000 – 0x3E FFFF Sector E (8K × 16)
0x3F 0000 – 0x3F 1FFF Sector D (8K × 16)
0x3F 2000 – 0x3F 3FFF Sector C (8K × 16)
0x3F 4000 – 0x3F 5FFF Sector B (8K × 16)
0x3F 6000 – 0x3F 7FF5 Sector A (8K × 16)
0x3F 7FF6 – 0x3F 7FF7
Boot-to-Flash Entry Point
(program branch instruction here)
0x3F 7FF8 – 0x3F 7FFF
Security Password (128-Bit)
(Do not program to all zeros)
NOTE
Addresses 0x3F 7FF0 – 0x3F 7FF5 are reserved for data and should not contain program
code.
