INS760EN-7 70/91
13.0 Appendix A
Flash Upgrading an Elite Panel
Connect to the control panel with Wintex using the ComUSB and save the profile.
Remove power from the control panel and connect the Flash interface to the
control panel and PC as shown:
Connect 10-way header to Programming Port.Pin 1 (Red) to arrows on Control
panel PCB as shown belowFlash
