13 FUSES AND RELAYS
13.1 FUSE AND RELAY IDENTIFICATION ______________________________________
Fuse Number Colour Amps Function
1 Accessory
2 Red 10 Air Seat
3 Yellow 20 Plus 1 Controller
4 Red 10 PTO Switch
5 Red 10 Accessory Socket
6 Blue 15 Working Lights
7 Orange 40 Glow Plugs (Diesel)
Relay Number Function
R1 Engine Stop Relay (Diesel)
R2 Starter (Gasoline)
R3 Glow Heater (Diesel)
R4 Starter (gasoline & Diesel)
Item Description
A Plus 1 Controller
B Audible Alarm
