en-78
9 ADJUSTMENTS
Fore/aft adjustment
The fore/aft adjustment is released by lifting the locking
lever.
• After the adjustment, the locking lever must latch into the desired position with an audible click. It should not
be possible to move the driver’s seat into another position when it is locked.
• Do not lift the locking lever with your leg or calf.
Lumbar support
The lumbar support increases both the seating comfort and
the performance of the driver. By turning the adjustment
knob upwards, the curvature in the upper part of the back-
rest cushion can be adjusted. By turning the knob down-
wards, the curvature in the lower part of the backrest
cushion can be adjusted.
0 = No curvature
1 = Max. curvature at the top
2 = Max. curvature at the bottom.
Backrest adjustment
Pull up the locking lever to release the backrest catch.
When releasing the backrest catch, do not apply load to the
backrest by pressing against it. By exerting pressure on or
off the front or rear part of the seat pan it can be moved to
the desired position. Release the locking lever to lock the
backrest.
• It should not be possible to move the backrest into another
position after it has been locked.
WARNING
Risk of accident.
Do not operate the locking lever while
driving.
WARNING
Risk of crushing.
only touch the lever at the indented grip,
do not reach back under the lever.
