SPECIFICATIONS 12
12.7 CUTTER DECK SPECIFICATION ________________________________________
12.8 CUTTING PERFORMANCE _____________________________________________
299.5cm (118 inch) width of cut:
3.24 hectares per hour at 12 kph.
8.0 acres per hour at 7.5mph
10% is included in these figures for normal overlaps and turning at the end of each cut.
328.4 cm (129.3 inch) width of cut:
3.564 hectares per hour at 12 kph.
8.80 acres per hour at 7.5mph
10% is included in these figures for normal overlaps and turning at the end of each cut.
152 cm (60 inch)
Deck (Front)
89 cm (35 inch) Deck
(Wing)
101.6 cm (40 inch) Deck
(Wing)
Construction
Bull nose profile, steel construction. Solid bumper rails, bolted assembly of all
impact and wearing parts.
Blade Length
533.4 mm
(21 inch)
457.2 mm
(18 inch)
533.4 mm
(21 inch)
Number of Blades 3 2 2
Blade Tip Speed
4207 m/minute
(13 802 feet/minute)
4940 m/minute
(16 207 feet/minute)
4207 m/minute
(13 802 feet/minute)
Overall Width Of Cut
299.5 cm
(118 inch)
328.4 cm
(129.3 inch)
Height of Cut
25 mm - 120 mm (1 inch - 4.75 inch) 6.5 mm (0.25 in) increments. Tools-less
adjustment.
Height of Cut Adjustment Front
Six castor wheels, with spacers. tyres 9 x 3.50 - 4.00 smooth, semi pneumatic
puncture proof, sealed precision ball bearings.
Height of Cut Adjustment Rear Front deck pin and slot. Wing deck chain and Pin
“Anti Scalp” Roll Three anti scalp rollers on the front of deck and four anti scalp rollers on the rear.
Transmission By Hydraulic motor to each cutter blade.
