Textron Jacobsen MP493 - Cutting Switch; Beacon Switch; Four Wheel Drive in Reverse Switch

en-23
5 CONTROLS
5.2.E CUTTER SWITCH __________________________________________________
Push the top of the switch and move the joystick toward the lower position.
Note. Make sure the speed limiter is in the mow position before the units are
lowered.
To stop the blades rotation, push the bottom of rocker switch.
When in the lifted position or the operator leaves the seat, blade rotation is
stopped.
5.2.F BEACON SWITCH (OPTIONAL)_______________________________________
Operates the vehicle beacon light.
5.2.G FOUR WHEEL DRIVE IN REVERSE DIRECTION SWITCH__________________
Select reverse drive and hold this switch, 4WD will engage.
4WD in the reverse direction is engaged while this switch is held. Release this
switch to disengage 4WD in the reverse direction.
