en-29
5 CONTROLS
12/05/2008
13/05/2008
18/05/2008
22/06/2008
22/06/2008
13/05/2008 @ 13:05
Max Temp - 110°C
Time above 100°C - 17 mins
Language Menu
English
Deutsch
Francais
Danish
Swedish
Dutch
5.2.H.12 DATALOGGING MENU _____________________________________________
The maximum number of recorded faults is 50. When 50 faults
are recorded, the next fault will write over the oldest fault.
This information is seen with the service tool or on the errors
page of the service menu. The standard buttons are shown.
Recorded errors are shown with the last error at the top of the
screen.
The fault / data record function has three actions. Each function
can contain a maximum of 50 faults.
1. The Inclinometer Records a slope of more than 26°.
2. The Engine Records an engine stop caused by the engine temperature or
loss of oil pressure.
3. Service Records a hydraulic filter by pass and the time between Services.
5.2.H.13 LANGUAGE MENU ________________________________________________
When you enter the page, the check mark () indicates the
current language. Move the check mark () to select the
language you will use. To select this language, use button four.
The title bar will change to the selected language.
The language options are English, German, French, Danish,
Swedish or Dutch.
