6 OPERATION
1
SLOPE CALCULATION CHART
Use One of these columns but not both The Gradient Result.
Height ‘C’ in inches
measured with a 1 yard
horizontal edge ‘A’
Height ‘C’ in millime-
ters measured with a 1
Metre horizontal edge
‘A’
Slope Angle ‘D’
Shown in
Degrees
Slope Angle ‘D’
Shown in
Percentage
34.88.3
100 5.7 10.0
150 8.5 15.0
6 9.5 16.7
200 11.3 20.0
7.5 11.8 20.8
225 12.7 22.5
9 250 14.0 25.0
275 15.4 27.5
10 15.5 27.8
300 16.7 30.0
11 17.0 30.6
325 18.0 32.5
12 18.4 33.3
350 19.3 35.0
13 19.9 36.1
375 20.6 37.5
14 21.3 38.9
400 21.8 40.0
15 22.6 41.7
425 23.0 42.5
16 24.0 44.4
475 25.4 47.5
18 500 26.6 50.0
20 29.1 55.6
600 31.0 60.0
25 34.8 69.4
800 38.7 80.0
30 39.8 83.3
900 42.0 90.0
36 1000 45.0 100.0
