FUSES AND RELAYS 10
FUSES
FUSE HOLDER 1
Fuse Rating Protected Circuits
1
2 15A Battery Positive Distribution Box to Starter Relay
3 7.5A Key Switch to Fuel Pump
4 10A Key Switch to Beacon And Horn
5 7.5A Key Switch to All Proximity Switches And Inclinometer
6 10A Key Switch to Accessory Sockets
FUSE HOLDER 2
Fuse Rating Protected Circuits
1 20A Key Switch to Machine Control Unit
2 10A Key Switch to Air Seat
3 5A Key Switch to Mow Cutter Switch
4 5A Key Switch to Visual Display Unit
5 5A Key Switch to Alternator
6 5A Key Switch to Transport Lock Solenoid
FUSE HOLDER 3
Fuse Rating Protected Circuits
1 5A Battery Positive Distribution Box to DSG Tracker
2 10A Battery Positive Distribution Box to Hazard Switch
3 5A Key Switch to Indicators
4 15A Key Switch to Front Lights
5 7.5A Key Switch to Rear Side, Brake And Reverse Lights
6
MAXI FUSE 4
Fuse Rating Protected Circuits
1 40A Battery Positive Distribution Box to Glow Plug Relay
2 40A Battery Positive Distribution Box to Cab Connector
