TFT Monsoon Series User Manual

©Copyright Task Force Tips LLC 2004-2018 LIY-200 October 11, 2018 Rev18
23
0 40 80 120 160 200 240 280 320
0
20
40
60
80
100
120
140
160
VERTICAL DISTANCE (FEET)
HORIZONTAL DISTANCE (FEET)
800604020
20
40
0
HORIZONTAL DISTANCE (METERS)
VERTICAL DISTANCE (METERS)
2.0 INCH TIP, 100 PSI, 1190 GPM
60 DEGREES
30 DEGREES
45 DEGREES
75 DEGREES
This graph is approximate only.
Critical applications should be tested in actual conditions to verify adequate reach.
Fig 6.1.2D
Eff ects of Elevation on Trajectory
0
10
40
20
80
0
40
80 120 160 200 240 280 320 360
HORIZONTAL DISTANCE (FEET)
2.00 INCH TIP, 100 PSI, 1190 GPM
VERTICAL DISTANCE (FEET)
NO WIND
20 MPH TAILWIND
20 MPH
HEADWIND
0015705520
VERTICAL DISTANCE (M)
HORIZONTAL DISTANCE (M)
This graph shows approximately how a moderate wind can aff ect stream reach. 1 ft = 0.3048 m
Fig 6.1.2E
Eff ects of Wind on Reach
