©Copyright Task Force Tips LLC 2004-2018 LIY-200 October 11, 2018 Rev18
27
INDEX DESCRIPTION QTY PART #
1
4" MONITOR BASE CLAMP
2
Y4435
3" MONITOR BASE CLAMP Y4436
2 WASHER 2 VW360X200-04
3 10-32 X 1 1/4 SOCKET HEAD SCREW 2 VT10-32SH1.2
4 CYLINDER NUT 2 Y4437
5
VO-RING-244
1
VO-244
VO-RING-236 VO-236
6
BASE CODE-RPF 4"
1
Y4400A
BASE CODE-RLF 3" Y4405A
BASE QUICK CONNECT 4.5"NHF SUBASSY Y4960
TILLER BASE QUICK CONNECT 4.5"NHF SUBASSY Y4961
7 5/16" TORLON BALL (49) PER RACE 98 VB.312TO
8 O-RING-350 1 VO-350
9 LOWER SEGMENT 1 Y4110A
10 CRANK WITH KNOB SUBASSEMBLY 1 A1623
11 1/4-20 X 1/2 BUTTON HEAD SCREW 4 VT25-20BH500
12 1/4-28 X 1/4 SOCKET SET SCREW 2 VT25-28SS250
13 3/8-24 X 3/8 SOCKET SET SCREW 8 VT37-24SS250
14 1/4" NPT PLUG 1 VFSP2M-SS
15 BALL PORT PLUG 1 Y4155
16 7/16" TORLON BALL (32) PER RACE 64 VB437TO
17 DOWEL PIN 1 VP312X1.00
18 ELEVATION HANDWHEEL SUBASSEMBLY 2 Y4941
19 NAME LABEL: MONSOON 1 Y4182
20 LOWER SHROUD 1 Y4130
21 10-24 X 1/2 SOCKET HEAD SCREW 1 VT10-24SH500
22 O-RING-245 2 VO-245
23 LOWER RING GEAR 1 Y4220
24 MIDDLE SEGMENT 1 Y4210A
25 UPPER RING GEAR 1 Y4320
26 1/2-20 X 3/8 SOCKET SET SCREW 1 VT50-20SS375
27
3.5” UPPER SEGMENT
1
Y4310A
2.5” UPPER SEGMENT Y4311
28 10-24 X 3/8 BUTTON HEAD SCREW 1 VT10-24BH375
29 5/16-18 X 3/4 SOCKET HEAD SCREW 2 VT31-18SH750
30 1/4-20 X 3/8 BUTTON HEAD SCREW 2 VT25-20BH375
31 UPPER SHROUD 1 Y4240
32 HALF RING GEAR 1 Y4230
33 3/16" TORLON BALL 146 V2120-TORLON
34 1/4-28 X 1/2 SOCKET SET SCREW 6 VT25-28SS500
35 HEADED BUSHING 2 Y4141
36 SHAFT SPRING 2 Y4159
37 WASHER 2 VW1.0X752-01
38 KEY 2 X225
39 DRIVE SHAFT 2 Y4160
40 12 DP WORM 2 X220
41 SPACER 2 Y4150
42 BEARING 2 VM4252
43 WASHER 2 VW97X595-048
44 SMALLEY RING 2 VR4365
45 SNAP RING 2 VR4220
46 COVER PLATE 2 Y4164
47 1/4-28 X 1/2 BUTTON HEAD SCREW 8 VT25-28BH500
48 PINION 1 Y4120
49 PLUG 2-1/4 MOUNTING HOLE 1 Y4162
50 3/8-24 X 5/16 SOCKET SET SCREW 2 VT37-24SS312
51 WASHER 2 VW938X591-03
