AS 682
Description, Operation and Maintenance Maintenance and Repair
ADS−B
7−25Ed. 10.07
JUMPER POSITION DEFINITION REMARKS
TP6 set
open
Analog IN to A/D converter disabled
Analog IN to A/D converter enabled
factory use, test purposes
default setting
TP7 set
open
TOA Trigger output disabled
TOA Trigger output enabled
factory use, test purposes
default setting
TP13 set
open
RX IRQ enabled
RX IRQ disabled
default setting
factory use, test purposes
TP14 set
open
TX IRQ enabled
TX IRQ disabled
default setting
factory use, test purposes
2 Signal Processing Board (SPB) 83142 71301 2 of 2
