AS 680/682
Description, Operation and Maintenance Monitor User Operation
ADS−B
6−1Ed. 10.07
CHAPTER 6
MONITOR USER OPERATION
In this chapter the operation of the TSC in Monitor User mode is described. The set of available func-
tions for the Monitor User is a subset of the Supervisor functions described within chapter 5.
Therefore only the differences to the Supervisor functions are listed within this chapter.
NOTE: Another application is the MTSC running on the RCMS. The MTSC functionality available
for the Monitor User on the RCMS is described in section 4.3.4.
The Monitor User is not allowed to change any parameter within the Notebook of the TSC. That
means, that all ’Edit’ buttons on any page of the TSC Notebook are hidden and not available (refer
to section 5.4.1).
Additionally for Monitor Users it is not allowed to configure or tune the behavior of the Ground Station
software. Therefore the page ’Process’ (see section 5.4.9) is not available, the tab is not provided
within the Monitor User’s notebook.
On some of the notebook pages described in chapter 5, the Monitor User’s functionality is restricted:
S On page ’’BITE’ (see section 5.4.3) no deactivation of Bite Status polling is possible, i.e. the fea-
ture ’Polling is activated’ can’t be deactivated by the Monitor User.
S On page ’Telegram Filter’ (see section 5.4.4) all buttons are hidden, i.e. no setting of downlink
format filters is possible. Only the ’Refresh’ button is active to update the page.
S In addition the Monitor User is not allowed to update or restart/reboot the Ground Station soft-
ware, i.e. on page ’Software’ there are some restrictions for the Monitor User.
The ’Upload’ (see section 5.4.13.5) and the ’Restart / Reboot’ function (see section 5.4.13.7) are
not available for the Monitor User within the notebook of page ’Software’ (see Fig. 6−1, next page).
